Forza Motorsport 8 (PC)ΒΆ
Switch to Console instructions
Enable UDP telemetry from HUD OPTIONS:
Start Forza Motorsport 8
Enter OPTIONS from the main menu
Enter HUD
Scroll to the bottom and enable DATA OUT
Enter your local IP address
127.0.0.1
Enter the port number
5607
Set DATA OUT PACKET FORMAT to
CAR DASH
Exit the game

Tip
These steps are automatically verified and performed by SIMRIG Control Center. Start the game and follow the prompts issued by SIMRIG Control Center. Or use the auto-configure tool on the Settings Page.
Open a CMD window as Administrator and run the command
CheckNetIsolation.exe LoopbackExempt -a -n=microsoft.apollobasegame_8wekyb3d8bbw1

This will allow Forza to send UDP packets to your local computer. This is not allowed by default since Forza is packaged as a UWP app.
Done
